| Video |
| Video System |
NTSC / PAL (auto detection) |
| Video Compression Format |
H.264 |
| Video Signal |
IP / TVI / CVI / Analog HD / 960H |
| Video Input |
8 quadbrid channels (IP / TVI / Analog HD / 960H) + 1 IP channel |
| Video Input Interface |
Analog Mode |
| IP Mode |
|
| Composite video signal 1 Vp-p 75Ω BNC |
| Ethernet, 10/100 Base-T |
|
| Video Output |
BNC |
| VGA |
| HDMI |
|
| YES (Spot Monitor supported) |
| YES (up to 1080P resolution / Spot Monitor supported) |
| YES (up to 4K2K resolution) |
|
| Video Resolution |
Analog Mode |
| IP Mode |
|
| 1080P / 720P / QHD / 960H / Frame / Field / CIF |
| 2592 x 1944** / 2048 x 1536** / 1920 x 1080 / 1280 x 720/ 640 x 480 / 320 x 2400 |
|
| Record & Backup |
| Max. Recording Rate |
Analog Mode |
| IP Mode |
|
| Up to 240 IPS @ 1920 x 1080 (8 channels) |
| UP to 270 IPS @ 1920 x 1080 (9 channels) |
|
| Recording Mode |
Manual / Timer / Motion / Alarm / Remote |
| Pre-alarm Recording |
YES |
| Playback Channel |
9CH |
| Backup Device |
USB 2.0 drive / Network |
| Regular Backup |
YES |
| Audio |
| Audio Input |
4 |
| Audio Output |
1 (Mono) |
| General |
| Hard Disk Storage |
10TB SATA HDD x 3 |
| SATA Interface |
YES |
| eSATA Interface |
YES (For external disk array connection) |
| Image Quality Setting |
SUPER BEST / BEST / HIGH / NORMAL |
| USB Mouse Control |
YES |
| Motion Detection Area |
16 × 12 grids per channel |
| Motion Detection Sensitivity |
3 adjustable parameters for accurate detection |
| Event Notification |
Push Video / Push Status / FTP / E-Mail |
| PTZ Control |
YES |
| Alarm I/O |
8 inputs, 1 output |
| IR Remote Control |
YES (IR receiver built-in) |
| RS485 |
YES |
| User Level |
4 user levels for different access privilege |
| Video Loss Detection |
YES |
| Camera Title |
Supports up to 25 letters |
| Video Adjustable |
Hue / Saturation / Contrast / Brightness |
| Date Display Format |
YY/MM/DD, DD/MM/YY & MM/DD/YY |
| Daylight Saving |
YES |
| Power Source (±10%) |
19V / 3.42A |
| Operating Temperature |
10ºC ~ 40ºC (50ºF ~104ºF) |
| Operating Humidity |
10% ~ 85% |
| Dimensions(mm)** |
430(W) x 65(H) x 338(D) |
| Net Weight (kg) |
3.2 |
| Network |
| Ethernet |
10/100 Base-T. Supports remote control and live view via Ethernet |
| Network Protocol |
TCP/IP, PPPOE, DHCP and DDNS |
| Remote Surveillance from PC |
| Compatible Operating System |
Windows & MAC |
| Compatible Program |
Web Browser: Windows Edge, Microsoft Internet Explorer, Google Chrome, Mozilla Firefox & SafariCMS Lite: 32CH central management software for Windows OS |
| Max. online users |
20 |
| Web Transmitting Compression Format |
H.264 |
| Network Live Audio |
YES |
| Remote Independent Operation |
YES |
| Remote Event Download & Playback |
YES |
| Mobile Surveillance |
| App |
EagleEyes |
| Compatible Devices |
iOS & Android devices |
| Push Video |
YES (4CH) |
| Push Status |
YES |
| Others |
| EaZy Networking |
YES |
| IVA |
YES (4 channels in analog mode) |
| DCCS Support |
YES |
| AVTECH Free DDNS service |
YES |
| Privacy Mask |
YES |
| Multiplex Operation |
Live display / record / playback / backup / network operations |
| System Recovery |
System auto recovery after power failure |
| Optional Peripherals |
Disk Array (AVX997 / AVX992) / HDMI Matrix (HDM02) / USB Joystick (AVX102) |
