| Video |
| Video System |
NTSC / PAL (auto-detection) |
| Video Compression Format |
H.264 |
| Video Signal |
IP / TVI / CVI / Analog HD / 960H |
| Video-Input |
8 Penta Brid channels (IP / TVI / CVI / Analog HD / 960H), within which IP channels are up to 2 channels |
| Video Input Interface |
Analog Mode |
| IP Mode |
|
| Composite video signal 1 Vp-p 75Ω BNC |
| Ethernet, 10/100 Base-T |
|
| Video Output |
BNC |
| VGA |
| HDMI |
|
| YES (Spot Monitor supported) |
| YES |
| YES |
|
| Video Resolution |
Analog Mode |
| IP Mode |
|
| Live & Playback: 1080P / 720P / QHD / 960H / Frame / Field / CIF Record**: 5MP / 4MP / 1080P / 720P / QHD / 960H / Frame / Field / CIF |
| Live & Playback: 1920 x 1080 / 1280 x 720 / 640 x 480 / 320 x 240 Record: 2592 x 1944 / 2048 x 1536 / 1920 x 1080 / 1280 x 720 / 640 x 480 / 320 x 240 |
|
| Record & Backup |
| Max. Recording Rate |
Analog Mode |
| IP Mode (2 channels) |
|
| Up to 12 IPS @ 2592 x 1944 (5MP)** Up to 15 IPS @ 2560 x 1440 (4MP)** Up to 120 IPS @ 1920 x 1080 Up to 240 IPS @ 1280 x 720 |
| Up to 12 IPS @ 2592 x 1944 (5MP) Up to 30 IPS @ 1920 x 1080 |
|
| Recording Mode |
Manual / Timer / Motion / Remote |
| Pre-alarm Recording |
YES |
| Playback Channel |
8CH |
| Quick Search |
Time / Motion search mod |
| Backup Device |
USB 2.0 drive / Network |
| Regular Backup |
YES |
| Audio |
| Audio Input |
1 audio input |
| Audio Output |
1 audio output (Mono) |
| General |
| Hard Disk Storage |
10TB SATA HDD x 1 |
| SATA Interface |
YES |
| Image Quality Setting |
SUPER BEST / BEST / HIGH / NORMAL |
| USB Mouse Control |
YES |
| Motion Detection Area |
16 × 12 grids per channel |
| Motion Detection Sensitivity |
3 adjustable parameters for accurate detection |
| Event Notification |
Push Status / FTP / E-Mail |
| IR Remote Control |
YES (IR receiver built-in) |
| Key Lock (Password Protection) |
YES |
| User Level |
4 user levels for different access privilege |
| Video Loss Detection |
YES |
| RS485 |
YES |
| Camera Title |
Supports up to 25 letters |
| Video Adjustable |
Hue / Saturation / Contrast / Brightness |
| Date Display Format |
YY/MM/DD, DD/MM/YY & MM/DD/YY |
| Daylight Saving |
YES |
| Power Source (±10%) |
DC12V / 2A |
| Operating Temperature |
10ºC ~ 40ºC (50ºF ~104ºF) |
| Operating Humidity |
10% ~ 85% |
| Dimensions(mm)** |
260(L) x 48(H) x 235.7(D) |
| Net Weight (kg) |
1.2 |
| Network |
| Ethernet |
10/100 Base-T. Supports remote control and live view via Ethernet |
| Network Protocol |
TCP/IP, PPPOE, DHCP and DDNS |
| Remote Surveillance from PC |
| Compatible Operating System |
Windows & MAC |
| Compatible Program |
Web Browser: Internet Explorer, Google Chrome & Safari CMS Lite: 32CH central management software for Windows OS QuickTime: For both Windows and MAC operating systems |
| Max. online users |
20 |
| Web Transmitting Compression Format |
H.264 |
| Network Live Audio |
YES |
| Remote Independent Operation |
YES |
| Remote Event Download & Playback |
YES |
| Mobile Surveillance |
| App |
EagleEyes |
| Compatible Devices |
iOS & Android devices |
| Push Status |
YES |
| Others |
| EaZy Networking |
YES |
| Spot Monitor Setup |
Call Monitor / Event Monitor / Live Monitor (Composite) |
| DCCS Support |
YES |
| AVTECH free DDNS service |
YES |
| Privacy Mask |
YES |
| Multiplex Operation |
Live display / record / playback / backup / network operations |
| System Recovery |
System auto recovery after power failure |
| Optional Peripherals |
HDMI Matrix (HDM02) / USB Joystick (AVX102) |
